Configuration

CP15BX Series c




PCoIP:	Integrated



Bezel Color:	Black, White or Beige



LCD Display:	15'' TFT active matrix panel



Max. Resolution:	XGA 1024 x 768



Contrast Ratio:	700:1 (Typ.)



Brightness:	225 cd/m² (Typ.)



Touch Screen:	Options: 5-wire resistive, SAW, capacitive and projected capacitive touch



Touch Panel:	Resistive/Capacitive (standard)



Aspect Ratio:	4:3



Response Time:	8 ms (Typ.)



Viewing Angle:	140°(h) x 130°(V) (Typ.)



Base:	Tilt down : -5° , Tilt up : +90°



Input Signals:	D-Sub15 pin ( VGA ) DVI-D



Audio System:	Headphone Out X1 Microphone In X1 Line In X1



Power Adaptor:	Universal Power Adapter Input AC 100~240V, 50~60 Hz Output DC 12V / TBD A, TBD W



Dimensions (WxHxD):	351.0 x 314.5 x 140.0 mm



Certifications:	CE, FCC, UL, C-UL, CCC

- The GVision P15BX utilizes a Teradici® PCoIP® (PC-over-IP) Chipset and VMware to deliver a powerful and secure virtual computing solution.

- High contrast color TFT LCD display support resolution up to 1024 x 768 . Compatible with IBM, VGA, VESA standards.

- Support DDC 1/2B for Plug & Play compatibility.

- Advanced OSD control for picture quality adjustment.

- Auto detects multi-signals input.

- VESA mounting. RoHS Compliance.

- Use PCoIP client processor.

- Stateless zero client, no data storage.

- Enable server-based remote imaging.

- WAN optimizations built into the protocol.

- Anti-Glare / Anti-Reflective tempered glass (MOQ) .

- Capacitive Touch Solution (MOQ) .

- Choice of black , beige or white housing .( Project Base )

- AC Power input Solution .

- Cable Management Stand .

- USB 2.0 Hub .
