Configuration Features Optional Accesories Order Information
Configuration
PCoIP: N/A
Bezel Color: Black or White
LCD Display: 15'' TFT active matrix panel
Max. Resolution: XGA 1024 x 768
Contrast Ratio: 700:1 (Typ.) w/o sensor or glass
Brightness: 250 CD/m2 (nits)
Touch Screen: 5-Wire Resistive, Capacitive (100% Elo Compatible)
Touch Panel: Serial & USB
Aspect Ratio: 4:3
Response Time: 8 ms (typical)
Viewing Angle: 140°(H) x 130°(V) (Typ.)
Base: Tilt down : -5° , Tilt up : +90°
Input Signals: VGA + DVI
Audio System: 1W / per channel driver
Power Adaptor: Univesal power adaptor input AC 100~240V, 50~60Hz: Output DC12V /4A
Dimensions (WxHxD): 351 x 314.5 x 140 mm
Certifications: CE / FCC UL / c-UL / TUV / CB CCC(optional) / RoHS / WEEE
Features
High contrast color TFT LCD display supports resolution up to 1024 x 768 Compatible with VGA, IBM and VESA signal standards (resolution/timing auto-detected) Compatible with non-standard signals (on request) Supports DDC 1/2B for Plug & Play compatibility Advanced OSD control for picture quality adjustment VESA standard mounting RoHS Compliance
Optional Accesories
Choice of black , or white color . Anti-Glare / Anti-Reflective tempered glass
Sunlight Readable
IP54 waterproof & dustproof sealed front bezel
Touch sensor technologies: resistive, surface capacitive
Video Signal input - Signal Connector: RCA / S-Video
[ Project Base ]
Cable Management Stand . USB 2.0 Hub (4 downstream ports and 1 upstream port). DVI-I Interface AC-in solution ( FCC / UL only )
Order Information
* P15PX-AA: VGA only
* P15PX-AB: VGA+DVI
*P15PX-OB-4690 No Stand; Analog + Digital ; Black; Gtouch Project; Resistive USB + Serial; Non-Branded
